Gravel pump performance parameters of the water
Type | Speed | Capacity | Head | Eff.η | Suction range | Greater flow particle size |
r/min | m³/h | m | % | m | mm | |
| 6/4D-G | 600-1400 | 10-70 | 3.5-51 | 30-50 | 6.5-7.5 | 82 |
| 8/6E-G | 800-1400 | 38-160 | 10-48 | 50-60 | 5.5-7 | 127 |
| 10/8F-G | 500-1000 | 60-272 | 13-50 | 45-65 | 2.5-7 | 178 |
| 12/10G-G | 400-850 | 100-420 | 11-58 | 50-70 | 5.5-8 | 220 |
| 14/12G-G | 300-700 | 140-880 | 6-66 | 60-68 | 2-8 | 241 |
| 18/16G-G | 250-500 | 240-1060 | 9-48 | 60-72 | 4-7 | 254 |
| 12/10G-GH | 350-700 | 170-620 | 28-78 | 60-72 | 2-8 | 210 |
| 10/8S-GH | 500-950 | 110-360 | 18-80 | 60-72 | 5-8 | 180 |
