Model description: pump product diameter: 250 mm multi-purpose mud pump: DS impeller diameter: 75 cm
Multi-purpose sediment water pump performance parameters
Type | Speed | Capacity | Head | Shaft power | Eff.η | Suction range | Auxiliary power |
r/min | m³/h | m | kw | % | m | kw | |
150DS-50 | 730-980 | 164-460 | 19-43 | 16-62 | 62-77 | 7-7.5 | 22-75 |
150DS-60 | 730-980 | 184-550 | 27-64 | 27-118 | 55-75 | 7-8 | 37-160 |
150DS-65 | 730-980 | 216-600 | 36-76 | 43-162 | 54-71 | 6-7.6 | 55-200 |
200DS-60 | 730-980 | 300-870 | 32-62 | 43-159 | 63-83 | 6-7.5 | 55-185 |
200DS-65 | 730-980 | 340-950 | 34-72 | 55-214 | 62-80 | 5.6-7 | 75-250 |
200DS-70 | 730-980 | 300-1000 | 41-87 | 67-273 | 55-76 | 6.2-7.2 | 90-315 |
250DS-65 | 730-980 | 410-1250 | 29-71 | 61-272 | 62-77 | 5.5-7.3 | 75-315 |
250DS-75 | 730-980 | 435-1480 | 44-98 | 99-444 | 62-76 | 5.9-7 | 132-560 |
250DS-85 | 730-980 | 527-1505 | 59-129 | 162-653 | 56-76 | 4.5-6.4 | 200-800 |
300DS-70 | 730-980 | 945-2333 | 36-77 | 152-506 | 72-81 | 3-6.1 | 185-630 |
300DS-90 | 590-730 | 745-1845 | 46-80 | 153-437 | 69-82 | 4.6-6.1 | 185-560 |
300DS-100 | 490-590 | 720-1830 | 37-66 | 125-366 | 64-81 | 5.9-7 | 185-450 |
